Mechanical multi limit switch with 3 mechanical switches + chisel plungers - Balluff (40 series) - model BNS 819-B03-D08-40-10 - Pre-equipped with solder pins + M16 cable entries - rated for (switches 1-3; AC) 250V - 3 x 1NO+1NC (snap-action contacts; SPDT single-pole changeover) - Rectangular body with 4.5mm through-holes - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - with 8mm switch spacing - Vertical mounting - IEC60947-5-1 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS819B03D084010

Mechanical multi limit switch with 2 mechanical switches + chisel plungers + LED function signalling (6-60V) - Balluff (100 series) - model BNS 819-D02-D16-100-10-FD - Pre-equipped with a wiring chamber with screw-clamp term. and M25 cable entry - rated for (switches 1-2; AC) 250V - 2 x 1NO+1NC (snap-action contacts; DPST; self-cleaning) - Rectangular body with mounting feet - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - with 16mm switch spacing - 5Hz max. switching frequency (switch 1-2) - Vertical mounting - IEC60947-5-1 compliant - DIN 43697 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS819D02D1610010FD

Mechanical multi limit switch with 3 mechanical switches + chisel plungers - Balluff (100 series) - model BNS 819-D03-D12-100-10 - Pre-equipped with a wiring chamber with screw-clamp term. and M25 cable entry - rated for (switches 1-3; AC) 250V - 3 x 1NO+1NC (snap-action contacts; DPST; self-cleaning) - Rectangular body with mounting feet - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - with 12mm switch spacing - 5Hz max. switching frequency (switch 1-3) - Vertical mounting - IEC60947-5-1 compliant - DIN 43697 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS819D03D1210010

Mechanical multi limit switch with 2 mechanical switches + chisel plungers - Balluff (40 series) - model BNS 819-B02-D08-40-10 - Pre-equipped with solder pins + M16 cable entries - rated for (switches 1-2; AC) 250V - 2 x 1NO+1NC (snap-action contacts; SPDT single-pole changeover) - Rectangular body with 4.5mm through-holes - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - with 8mm switch spacing - Vertical mounting - IEC60947-5-1 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS819B02D084010

Mechanical multi limit switch with 3 mechanical switches + roller plungers - Balluff (100 series) - model BNS 819-D03-R12-100-10 - Pre-equipped with a wiring chamber with screw-clamp term. and M25 cable entry - rated for (switches 1-3; AC) 250V - 3 x 1NO+1NC (snap-action contacts; DPST; self-cleaning) - Rectangular body with mounting feet - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - with 12mm switch spacing - 5Hz max. switching frequency (switch 1-3) - Vertical mounting - IEC60947-5-1 compliant - DIN 43697 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS819D03R1210010

Mechanical multi limit switch with 3 mechanical switches + roller plungers - Balluff (62 series) - model BNS 819-D03-R16-62-10 - Pre-equipped with a wiring chamber with screw-clamp term. and M20 cable entry - rated for (switches 1-3; AC) 250V - 3 x 1NO+1NC (snap-action contacts; DPST; self-cleaning) - Rectangular body with mounting feet - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - with 16mm switch spacing - 5Hz max. switching frequency (switch 1-3) - Vertical mounting - IEC60947-5-1 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS819D03R166210

Mechanical multi limit switch with 3 mechanical switches + roller plungers + LED function signalling (6-60V) - Balluff (100 series) - model BNS 819-D03-R16-100-10-FD - Pre-equipped with a wiring chamber with screw-clamp term. and M25 cable entry - rated for (switches 1-3; AC) 250V - 3 x 1NO+1NC (snap-action contacts; DPST; self-cleaning) - Rectangular body with mounting feet - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - with 16mm switch spacing - 5Hz max. switching frequency (switch 1-3) - Vertical mounting - IEC60947-5-1 compliant - DIN 43697 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS819D03R1610010FD

Mechanical multi limit switch with 3 mechanical switches + roller plungers - Balluff (100 series) - model BNS 819-D03-R16-100-10 - Pre-equipped with a wiring chamber with screw-clamp term. and M25 cable entry - rated for (switches 1-3; AC) 250V - 3 x 1NO+1NC (snap-action contacts; DPST; self-cleaning) - Rectangular body with mounting feet - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - with 16mm switch spacing - 5Hz max. switching frequency (switch 1-3) - Vertical mounting - IEC60947-5-1 compliant - DIN 43697 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS819D03R1610010

Mechanical multi limit switch with 3 mechanical switches + roller plungers + LED function signalling (6-60V) - Balluff (62 series) - model BNS 819-D03-R12-62-10-FD - Pre-equipped with a wiring chamber with screw-clamp term. and M20 cable entry - rated for (switches 1-3; AC) 250V - 3 x 1NO+1NC (snap-action contacts; DPST; self-cleaning) - Rectangular body with mounting feet - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - with 12mm switch spacing - 5Hz max. switching frequency (switch 1-3) - Vertical mounting - IEC60947-5-1 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS819D03R126210FD

Mechanical multi limit switch with 3 mechanical switches + roller plungers - Balluff (62 series) - model BNS 819-D03-R12-62-10 - Pre-equipped with a wiring chamber with screw-clamp term. and M20 cable entry - rated for (switches 1-3; AC) 250V - 3 x 1NO+1NC (snap-action contacts; DPST; self-cleaning) - Rectangular body with mounting feet - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - with 12mm switch spacing - 5Hz max. switching frequency (switch 1-3) - Vertical mounting - IEC60947-5-1 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS819D03R126210
