MLV41-8-H-120-RT-6628 PEPPERL+FUCHS - Part number: 272298

Datasheet excerpt: Technical data of  MLV41-8-H-120-RT-6628 Product Description Triangulation sensor with background suppression in corrosion-resistant metal housing with sensing-by-ranging functionality, IO-Link interface, 120 mm adjustable detection range, red light, push-pull output, M12 plug General specifications Detection range20 ... 120 mm Black-white difference < 3% Adjustment range20 ... 120 mm Reference targetstandard white, 100 mm x 100 mm Light sourceLED Light typemodulated visible red light Diameter of the light spot4 mm at sensor range 100 mm Opening angle2.5 ° Ambient light limit25000 Lux Functional safety related parameters MTTFd500 a Mission Time (TM)20 a Diagnostic Coverage (DC)0 % Indicators/operating means Operation indicatorLED green, statically lit Power on , Undervoltage indicator: Green LED, pulsing (0.8 Hz) , short-circuit : LED green flashing (4 Hz) Function indicator2 LEDs yellowON: object inside the scanning rangeOFF: object outside the scanning range Control elementsSensing range adjuster Electrical specifications Operating voltage10 ... 30 V DC , class 2 Ripplemax. 10 % No-load supply currentmax. 25 mA at 24 V supply voltage Output Signal output2 push-pull (4 in 1) outputs, short-circuit protected, reverse polarity protected Switching voltagemax. 30 V DC Switching currentmax. 100 mA Voltage drop≤ 2 V DC Switching frequency200 Hz Response time2.5 ms Conformity Product standardEN 60947-5-2 Approvals and certificates EAC conformityTR CU 020/2011 UL approvalcULus Listed 57M3 (Only in association with UL Class 2 power supply; Type 1 enclosure) CCC approvalCCC approval / marking not required for products rated ≤36 V Ambient conditions Ambient temperature-20 ... 60 °C (-4 ... 140 °F) Storage temperature-40 ... 75 °C (-40 ... 167 °F) Mechanical specifications Housing width31 mm Housing height56.5 mm Housing depth13.6 mm Degree of protectionIP67 Connectionwith M9, 5-pin metal connector Material HousingAluminum , Delta-Seal coated Optical faceglass pane Connectormetal Mass40 g Classifications SystemClasscode ECLASS 11.027270904 ECLASS 10.0.127270904 ECLASS 9.027270904 ECLASS 8.027270904 ECLASS 5.127270904 ETIM 8.0EC002719 ETIM 7.0EC002719 ETIM 6.0EC002719 ETIM 5.0EC002719 UNSPSC 12.139121528 Datasheet excerpt: Technical data of  MLV41-8-H-120-RT-6628 Product Description Triangulation sensor with background suppression in corrosion-resistant metal housing with sensing-by-ranging functionality, IO-Link interface, 120 mm adjustable detection range, red light, push-pull output, M12 plug General specifications Detection range20 ... 120 mm Black-white difference < 3% Adjustment range20 ... 120 mm Reference targetstandard white, 100 mm x 100 mm Light sourceLED Light typemodulated visible red light Diameter of the light spot4 mm at sensor range 100 mm Opening angle2.5 ° Ambient light limit25000 Lux Functional safety related parameters MTTFd500 a Mission Time (TM)20 a Diagnostic Coverage (DC)0 % Indicators/operating means Operation indicatorLED green, statically lit Power on , Undervoltage indicator: Green LED, pulsing (0.8 Hz) , short-circuit : LED green flashing (4 Hz) Function indicator2 LEDs yellowON: object inside the scanning rangeOFF: object outside the scanning range Control elementsSensing range adjuster Electrical specifications Operating voltage10 ... 30 V DC , class 2 Ripplemax. 10 % No-load supply currentmax. 25 mA at 24 V supply voltage Output Signal output2 push-pull (4 in 1) outputs, short-circuit protected, reverse polarity protected Switching voltagemax. 30 V DC Switching currentmax. 100 mA Voltage drop≤ 2 V DC Switching frequency200 Hz Response time2.5 ms Conformity Product standardEN 60947-5-2 Approvals and certificates EAC conformityTR CU 020/2011 UL approvalcULus Listed 57M3 (Only in association with UL Class 2 power supply; Type 1 enclosure) CCC approvalCCC approval / marking not required for products rated ≤36 V Ambient conditions Ambient temperature-20 ... 60 °C (-4 ... 140 °F) Storage temperature-40 ... 75 °C (-40 ... 167 °F) Mechanical specifications Housing width31 mm Housing height56.5 mm Housing depth13.6 mm Degree of protectionIP67 Connectionwith M9, 5-pin metal connector Material HousingAluminum , Delta-Seal coated Optical faceglass pane Connectormetal Mass40 g Classifications SystemClasscode ECLASS 11.027270904 ECLASS 10.0.127270904 ECLASS 9.027270904 ECLASS 8.027270904 ECLASS 5.127270904 ETIM 8.0EC002719 ETIM 7.0EC002719 ETIM 6.0EC002719 ETIM 5.0EC002719 UNSPSC 12.139121528
