NJ2-PD-US-2.875-V93 PEPPERL+FUCHS - Part number: 906643

Datasheet excerpt: Technical data of  NJ2-PD-US-2.875-V93 Product Description Cylinder Position Switch General specifications Switching functionNormally open (NO) Output typeTwo-wire Rated operating distance2 mm Installationflush Output polarityAC/DC Assured operating distance0 ... 1.62 mm Reduction factor rAl 0.4 Reduction factor r304 0.85 Output type2-wire Nominal ratings Operating voltage20 ... 250 V AC/20 ... 300 V DC Switching frequency0 ... 20 Hz Hysteresis10 ... 20 % 15 typ. Reverse polarity protectionyes Short-circuit protectionyes Voltage drop≤ 7 V Momentary current(20 ms, 0.1 Hz)max. 3 A Operating current8 ... 300 mA Off-state current< 1.7 mA Mag. Field strength, AC fields250 mT Mag. Field strength, DC fields100 mT Limit data Operating pressure dynamically3000 psi Indicators/operating means LED greenPower on LED redOutput status LED red/greenShort circuit/overload indication Standard conformity StandardsEN 60947-5-2 Approvals and certificates UL approvalcULus Listed, General Purpose CSA approvalcCSAus Listed, General Purpose Ambient conditions Ambient temperature-25 ... 70 °C (-13 ... 158 °F) Mechanical specifications Connection typeConnector plug 7/8 inch-16 UN , 3-pin Degree of protectionIP67 MaterialHousing: zinc Probe: aluminum NoteX = 2.875 in (73 mm) Classifications SystemClasscode ECLASS 11.027270101 ECLASS 10.0.127270101 ECLASS 9.027270101 ECLASS 8.027270101 ECLASS 5.127270101 ETIM 8.0EC002714 ETIM 7.0EC002714 ETIM 6.0EC002714 ETIM 5.0EC002714 UNSPSC 12.139121550 Datasheet excerpt: Technical data of  NJ2-PD-US-2.875-V93 Product Description Cylinder Position Switch General specifications Switching functionNormally open (NO) Output typeTwo-wire Rated operating distance2 mm Installationflush Output polarityAC/DC Assured operating distance0 ... 1.62 mm Reduction factor rAl 0.4 Reduction factor r304 0.85 Output type2-wire Nominal ratings Operating voltage20 ... 250 V AC/20 ... 300 V DC Switching frequency0 ... 20 Hz Hysteresis10 ... 20 % 15 typ. Reverse polarity protectionyes Short-circuit protectionyes Voltage drop≤ 7 V Momentary current(20 ms, 0.1 Hz)max. 3 A Operating current8 ... 300 mA Off-state current< 1.7 mA Mag. Field strength, AC fields250 mT Mag. Field strength, DC fields100 mT Limit data Operating pressure dynamically3000 psi Indicators/operating means LED greenPower on LED redOutput status LED red/greenShort circuit/overload indication Standard conformity StandardsEN 60947-5-2 Approvals and certificates UL approvalcULus Listed, General Purpose CSA approvalcCSAus Listed, General Purpose Ambient conditions Ambient temperature-25 ... 70 °C (-13 ... 158 °F) Mechanical specifications Connection typeConnector plug 7/8 inch-16 UN , 3-pin Degree of protectionIP67 MaterialHousing: zinc Probe: aluminum NoteX = 2.875 in (73 mm) Classifications SystemClasscode ECLASS 11.027270101 ECLASS 10.0.127270101 ECLASS 9.027270101 ECLASS 8.027270101 ECLASS 5.127270101 ETIM 8.0EC002714 ETIM 7.0EC002714 ETIM 6.0EC002714 ETIM 5.0EC002714 UNSPSC 12.139121550
