用于颜色读取的光纤装置，与 E3NXW 模块的通信接口

Photo-electric contrast difference registration sensor / switch with diffuse sensing + focused beam - Balluff (67M series) - model BKT 67M-003-U-S92 - 6-12mm sensing range - red / green / blue light (630 / 520 / 465nm) - Pre-equipped with a M12 male connector - 1 x digital output (PNP/NPN transistor; 100mA) (NO (Normally Open) or NC (Normally Closed) + light-ON / light-OFF setting operation) + 1 x analog output (1-5.5Vdc) - Rectangular shape - 10-30Vdc (12Vdc / 24Vdc nom.) supply voltage - Rated for +14...+131°F / -10...+55°C ambient - IP67 - Painted die-cast Aluminium housing + Glass sensing surface - 20000Hz / 20kHz max. switching frequency - Surface with through-holes (M5 screw) mounting - time function ON / OFF setting - TEACH mode setting - adjustable contrast switching point - switching output setting - equivalent to BKT67M003US92

Class 1 laser photo-electric contrast difference registration sensor / switch with diffuse sensing + focused laser - Balluff (6K series) - model BKT 6K-002-P-S75 - 1-250mm sensing range - red Laser light (650nm) - Pre-equipped with a 4-pin M8 male connector - 1 x digital output (PNP transistor; 100mA) (NO (Normally Open) or NC (Normally Closed) + light-ON / light-OFF setting operation) - Rectangular shape - 10-30Vdc (12Vdc / 24Vdc nom.) supply voltage - Rated for -4...+140°F / -20...+60°C ambient - IP67 - ABS (Acrylonitrile Butadiene Styrene) housing + PMMA (Acrylic) sensing surface - 1500Hz / 1.5kHz max. switching frequency - Surface with through-holes (M3 screw) mounting - TEACH mode setting - adjustable contrast switching point - equivalent to BKT6K002PS75

Class 1 laser photo-electric contrast difference registration sensor / switch with diffuse sensing + focused laser - Balluff (6K series) - model BKT 6K-002-P-S49 - 1-250mm sensing range - red Laser light (650nm) - Pre-equipped with a 3-pin M8 male connector - 1 x digital output (PNP transistor; 100mA) (NO (Normally Open) or NC (Normally Closed) + light-ON / light-OFF setting operation) - Rectangular shape - 10-30Vdc (12Vdc / 24Vdc nom.) supply voltage - Rated for -4...+140°F / -20...+60°C ambient - IP67 - ABS (Acrylonitrile Butadiene Styrene) housing + PMMA (Acrylic) sensing surface - 1500Hz / 1.5kHz max. switching frequency - Surface with through-holes (M3 screw) mounting - TEACH mode setting - adjustable contrast switching point - equivalent to BKT6K002PS49

Class 1 laser photo-electric contrast difference registration sensor / switch with diffuse sensing + focused laser - Balluff (6K series) - model BKT 6K-002-P-02 - 1-250mm sensing range - red Laser light (650nm) - Pre-wired with a 2m cable terminated with bare end flying leads - 1 x digital output (PNP transistor; 100mA) (NO (Normally Open) or NC (Normally Closed) + light-ON / light-OFF setting operation) - Rectangular shape - 10-30Vdc (12Vdc / 24Vdc nom.) supply voltage - Rated for -4...+140°F / -20...+60°C ambient - IP67 - ABS (Acrylonitrile Butadiene Styrene) housing + PVC (Polyvinylchloride) cable jacket + PMMA (Acrylic) sensing surface - 1500Hz / 1.5kHz max. switching frequency - Surface with through-holes (M3 screw) mounting - TEACH mode setting - adjustable contrast switching point - equivalent to BKT6K002P02

Class 1 laser photo-electric contrast difference registration sensor / switch with diffuse sensing + focused laser - Balluff (6K series) - model BKT 6K-002-N-S75 - 1-250mm sensing range - red Laser light (650nm) - Pre-equipped with a 4-pin M8 male connector - 1 x digital output (NPN transistor; 100mA) (NO (Normally Open) or NC (Normally Closed) + light-ON / light-OFF setting operation) - Rectangular shape - 10-30Vdc (12Vdc / 24Vdc nom.) supply voltage - Rated for -4...+140°F / -20...+60°C ambient - IP67 - ABS (Acrylonitrile Butadiene Styrene) housing + PMMA (Acrylic) sensing surface - 1500Hz / 1.5kHz max. switching frequency - Surface with through-holes (M3 screw) mounting - TEACH mode setting - adjustable contrast switching point - equivalent to BKT6K002NS75

Class 1 laser photo-electric contrast difference registration sensor / switch with diffuse sensing + focused laser - Balluff (6K series) - model BKT 6K-002-N-02 - 1-250mm sensing range - red Laser light (650nm) - Pre-wired with a 2m cable terminated with bare end flying leads - 1 x digital output (NPN transistor; 100mA) (NO (Normally Open) or NC (Normally Closed) + light-ON / light-OFF setting operation) - Rectangular shape - 10-30Vdc (12Vdc / 24Vdc nom.) supply voltage - Rated for -4...+140°F / -20...+60°C ambient - IP67 - ABS (Acrylonitrile Butadiene Styrene) housing + PVC (Polyvinylchloride) cable jacket + PMMA (Acrylic) sensing surface - 1500Hz / 1.5kHz max. switching frequency - Surface with through-holes (M3 screw) mounting - TEACH mode setting - adjustable contrast switching point - equivalent to BKT6K002N02

Photo-electric contrast difference registration sensor / switch with diffuse sensing + focused beam - Balluff (67M series) - model BKT 67M-005-U-S92 - 6-12mm sensing range - red / green / blue light (630 / 520 / 465nm) - Pre-equipped with a M12 male connector - 1 x digital output (PNP/NPN transistor; 100mA) (NO (Normally Open) or NC (Normally Closed) + light-ON / light-OFF setting operation) - Rectangular shape - 10-30Vdc (12Vdc / 24Vdc nom.) supply voltage - Rated for +14...+131°F / -10...+55°C ambient - IP67 - Painted die-cast Aluminium housing + Glass sensing surface - 30000Hz / 30kHz max. switching frequency - Surface with through-holes (M5 screw) mounting - time function ON / OFF setting - adjustable delay time - TEACH mode setting - adjustable contrast switching point - adjustable hysteresis - segment display setting - switching output setting - equivalent to BKT67M005US92

Photo-electric contrast difference registration sensor / switch with diffuse sensing + focused beam - Balluff (67M series) - model BKT 67M-004-U-S92 - 6-12mm sensing range - red / green / blue light (630 / 520 / 465nm) - Pre-equipped with a M12 male connector - 1 x digital output (PNP/NPN transistor; 100mA) (NO (Normally Open) or NC (Normally Closed) + light-ON / light-OFF setting operation) + 1 x analog output (1-5.5Vdc) - Rectangular shape - 10-30Vdc (12Vdc / 24Vdc nom.) supply voltage - Rated for +14...+131°F / -10...+55°C ambient - IP67 - Painted die-cast Aluminium housing + Glass sensing surface - 20000Hz / 20kHz max. switching frequency - Surface with through-holes (M5 screw) mounting - time function ON / OFF setting - TEACH mode setting - adjustable contrast switching point - switching output setting - equivalent to BKT67M004US92

Photo-electric contrast difference registration sensor / switch with diffuse sensing + focused beam - Balluff (67M series) - model BKT 67M-002-U-S92 - 6-12mm sensing range - red / green / blue light (630 / 520 / 465nm) - Pre-equipped with a M12 male connector - 1 x digital output (PNP/NPN transistor; 100mA) (NO (Normally Open) or NC (Normally Closed) + light-ON / light-OFF setting operation) + 1 x analog output (1-5.5Vdc) - Rectangular shape - 10-30Vdc (12Vdc / 24Vdc nom.) supply voltage - Rated for +14...+131°F / -10...+55°C ambient - IP67 - Painted die-cast Aluminium housing + PMMA (Acrylic) sensing surface - 15000Hz / 15kHz max. switching frequency - Surface with through-holes (M5 screw) mounting - time function ON / OFF setting - TEACH mode setting - adjustable contrast switching point - switching output setting - equivalent to BKT67M002US92
