Photoelectric slot sensor GL80-RT/32/40a/98a GL80-RT/32/40a/98a Optimized for the detection of small parts High switching frequency Multiple device installation possible, no mutual interference (no cross-talk) Sensitivity adjuster and light-on/dark-on changeover switch as standard features of this series Visible red light Degree of protection IP67 cULus approval Diecast zinc housing, powder coated

Fork-shaped photo-electric edge sensor head with through-beam sensing + 80mm x 30mm active window - Balluff (F80 series) - model BOH AR-F80-003-01-S49F - red LED beam light (645nm) - Pre-wired with a 1m pigtail terminated by a M8 female connector - U-shape body - Rated for +14...+131°F / -10...+55°C ambient - IP65 - Anodized black Aluminium housing + PUR (Polyurethane) cable jacket + PMMA (Acrylic) sensing surface - Surface with through-holes (M5 screw) mounting - equivalent to BOHARF8000301S49F

Photo-electric angle sensor / switch emitter + receiver pair with through-beam sensing + 60mm gap / passageway + divergent LED beam + adjustable sensitivity - Balluff - model BWL 4040D-R011-S49 - red LED beam light (636nm) - Pre-equipped with a 3-pin M8 male connector - 1 x digital output (PNP transistor; 200mA) (NO (Normally Open) or NC (Normally Closed) + light-ON / light-OFF setting operation) - L-shape body - 10-30Vdc (12Vdc / 24Vdc nom.) supply voltage - Rated for +14...+140°F / -10...+60°C ambient - IP67 - Die-cast Zinc housing (painted) + Glass sensing surface - 1500Hz / 1.5kHz max. switching frequency - Surface with through-holes (M4 screw) mounting - equivalent to BWL4040DR011S49

Class 1 laser photo-electric angle sensor / switch emitter + receiver pair with through-beam sensing + 60mm gap / passageway + collimated beam + adjustable sensitivity - Balluff - model BWL 4040D-L011-S49 - red Laser light (655nm) - Pre-equipped with a 3-pin M8 male connector - 1 x digital output (PNP transistor; 200mA) (NO (Normally Open) or NC (Normally Closed) + light-ON / light-OFF setting operation) - L-shape body - 10-30Vdc (12Vdc / 24Vdc nom.) supply voltage - Rated for +14...+140°F / -10...+60°C ambient - IP67 - Die-cast Zinc housing (painted) + Glass sensing surface - 5000Hz / 5kHz max. switching frequency - Surface with through-holes (M4 screw) mounting - equivalent to BWL4040DL011S49

Photo-electric angle sensor / switch emitter + receiver pair with through-beam sensing + 60mm gap / passageway + divergent beam + adjustable sensitivity - Balluff - model BWL 4040D-I011-S49 - Infrared (IR) light (880nm) - Pre-equipped with a 3-pin M8 male connector - 1 x digital output (PNP transistor; 200mA) (NO (Normally Open) or NC (Normally Closed) + light-ON / light-OFF setting operation) - L-shape body - 10-30Vdc (12Vdc / 24Vdc nom.) supply voltage - Rated for +14...+140°F / -10...+60°C ambient - IP67 - Die-cast Zinc housing (painted) + Glass sensing surface - 2000Hz / 2kHz max. switching frequency - Surface with through-holes (M4 screw) mounting - equivalent to BWL4040DI011S49

Photo-electric angle sensor / switch emitter + receiver pair with through-beam sensing + 31mm gap / passageway + divergent beam - Balluff - model BWL 2222C-001-S4 - Infrared (IR) light (880nm) - Pre-equipped with a 4-pin M12 male connector (45° angled connection) - 1 x digital output (PNP transistor; 200mA) (NO (Normally Open) operation) - L-shape body - 10-30Vdc (12Vdc / 24Vdc nom.) supply voltage - Rated for +14...+140°F / -10...+60°C ambient - IP67 - Powder-coated 1.4408 stainless steel housing + Polymer sensing surface - 1000Hz / 1kHz max. switching frequency - Surface with through-holes (M6 screw) mounting - equivalent to BWL2222C001S4

Photo-electric angle sensor / switch emitter + receiver pair with through-beam sensing + 31mm gap / passageway + divergent beam - Balluff - model BWL 2222B-001-S4 - Infrared (IR) light (880nm) - Pre-equipped with a 4-pin M12 male connector - 1 x digital output (PNP transistor; 200mA) (NO (Normally Open) operation) - L-shape body - 10-30Vdc (12Vdc / 24Vdc nom.) supply voltage - Rated for +14...+140°F / -10...+60°C ambient - IP67 - Powder-coated 1.4408 stainless steel housing + Polymer sensing surface - 1000Hz / 1kHz max. switching frequency - Surface with through-holes (M6 screw) mounting - equivalent to BWL2222B001S4

Photo-electric angle sensor / switch emitter + receiver pair with through-beam sensing + 160mm gap / passageway + divergent LED beam + adjustable sensitivity - Balluff - model BWL 110110D-R011-S49 - red LED beam light (636nm) - Pre-equipped with a 3-pin M8 male connector - 1 x digital output (PNP transistor; 200mA) (NO (Normally Open) or NC (Normally Closed) + light-ON / light-OFF setting operation) - L-shape body - 10-30Vdc (12Vdc / 24Vdc nom.) supply voltage - Rated for +14...+140°F / -10...+60°C ambient - IP67 - Die-cast Zinc housing (painted) + Glass sensing surface - 1500Hz / 1.5kHz max. switching frequency - Surface with through-holes (M4 screw) mounting - equivalent to BWL110110DR011S49

Class 1 laser photo-electric angle sensor / switch emitter + receiver pair with through-beam sensing + 160mm gap / passageway + collimated beam + adjustable sensitivity - Balluff - model BWL 110110D-L011-S49 - red Laser light (655nm) - Pre-equipped with a 3-pin M8 male connector - 1 x digital output (PNP transistor; 200mA) (NO (Normally Open) or NC (Normally Closed) + light-ON / light-OFF setting operation) - L-shape body - 10-30Vdc (12Vdc / 24Vdc nom.) supply voltage - Rated for +14...+140°F / -10...+60°C ambient - IP67 - Die-cast Zinc housing (painted) + Glass sensing surface - 5000Hz / 5kHz max. switching frequency - Surface with through-holes (M4 screw) mounting - equivalent to BWL110110DL011S49

Photo-electric angle sensor / switch emitter + receiver pair with through-beam sensing + 160mm gap / passageway + divergent beam + adjustable sensitivity - Balluff - model BWL 110110D-I011-S49 - Infrared (IR) light (880nm) - Pre-equipped with a 3-pin M8 male connector - 1 x digital output (PNP transistor; 200mA) (NO (Normally Open) or NC (Normally Closed) + light-ON / light-OFF setting operation) - L-shape body - 10-30Vdc (12Vdc / 24Vdc nom.) supply voltage - Rated for +14...+140°F / -10...+60°C ambient - IP67 - Die-cast Zinc housing (painted) + Glass sensing surface - 2000Hz / 2kHz max. switching frequency - Surface with through-holes (M4 screw) mounting - equivalent to BWL110110DI011S49
