Inductive distance sensors 1099 products

Filter by
Price
USD USD
Manufacturers
Operating voltage
Type of electric connection
Ambient temperature
Type of analogy output
Construction type housing
Width sensor
Height of sensor
Length of sensor
Material of cable sheath
Diameter sensor
Mechanical mounting condition for sensor
Supply voltage
Operation agent-safety class
Measuring range length
Relative linearity deflection
Limiting frequency
Material active area of sensor
Filter
BAW Z01AC-UAD50B-DP03-K BALLUFF - Part Number: BAW003E
NFS

BAW Z01AC-UAD50B-DP03-K BALLUFF - Part Number: BAW003E

Inductive distance sensor transmitter with built-in temp. measurement - Balluff - model BAW Z01AC-UAD50B-DP03-K - 1-5mm sensing range - Pre-wired with a 3m cable terminated with bare end flying leads - 1 x analog output (0-10Vdc) + 1 x analog output (temperature) - Rectangular shape - 15-30Vdc (24Vdc nom.) supply voltage - Rated for +14...+140°F / -10...+60°C ambient - IP67 - Anodized Aluminium housing + PUR (Polyurethane) cable jacket + PA12 (polyamide) sensing surface - non-flush mounting - equivalent to BAWZ01ACUAD50BDP03K
compare
USD438.32 Price
Out of Stock - Backorder
BIP AD2-B040-02-S4 BALLUFF - Part Number: BIP0002
NFS

BIP AD2-B040-02-S4 BALLUFF - Part Number: BIP0002

Linear inductive sensor - Balluff - model BIP AD2-B040-02-S4 - 40mm measuring length - 1-3mm (read dist.) sensing range - Pre-equipped with a 3-pin M12 male connector - 1 x analog output (0-10Vdc) - Rectangular shape - 15-30Vdc (24Vdc nom.) supply voltage - Rated for -13...+185°F / -25...+85°C ambient - IP67 - PA (polyamide) housing + PA (polyamide) sensing surface - equivalent to BIPAD2B04002S4
compare
USD391.85 Price
Out of Stock - Backorder
BIP AD0-F014-01-EP00,5-S4-507 BALLUFF - Part Number: BIP0021
NFS

BIP AD0-F014-01-EP00,5-S4-507 BALLUFF - Part Number: BIP0021

Linear inductive sensor - Balluff - model BIP AD0-F014-01-EP00.5-S4-507 - 7mm measuring length - Pre-wired with a 50cm pigtail terminated by a 3-pin M12 male connector - 1 x analog output (0-10Vdc) - Rectangular shape - 15-30Vdc (24Vdc nom.) supply voltage - Rated for -13...+158°F / -25...+70°C ambient - IP67 - PA (polyamide) housing + PUR (Polyurethane) cable jacket + PA (polyamide) sensing surface - equivalent to BIPAD0F01401EP00.5S4507
compare
USD486.82 Price
Out of Stock - Backorder
BAW Z08EO-UAD20B-S04G-H11 BALLUFF - Part Number: BAW0040
NFS

BAW Z08EO-UAD20B-S04G-H11 BALLUFF - Part Number: BAW0040

Inductive distance sensor transmitter - Balluff - model BAW Z08EO-UAD20B-S04G-H11 - 0.5-2mm sensing range - Pre-equipped with a 3-pin M12 male connector - 1 x analog output (voltage; falling on approach) - Cylindrical / barrel fully threaded body with M12 threads - 15-30Vdc (24Vdc nom.) supply voltage - Rated for -13...+185°F / -25...+85°C ambient - Rated for 500bar - IP68 - Stainless steel housing + Ceramic sensing surface - flush mounting - equivalent to BAWZ08EOUAD20BS04GH11
compare
USD768.52 Price
Out of Stock - Backorder
BAW Z05AC-BLD50B-BP00,75-GS04 BALLUFF - Part Number: BAW003W
NFS

BAW Z05AC-BLD50B-BP00,75-GS04 BALLUFF - Part Number: BAW003W

Inductive distance sensor with TEACH-in mode - Balluff - model BAW Z05AC-BLD50B-BP00.75-GS04 - 1-5mm sensing range - Pre-wired with a 75cm pigtail terminated by a 4-pin M12 male connector - Rectangular shape - 18-30Vdc (24Vdc nom.) supply voltage - Rated for +14...+140°F / -10...+60°C ambient - IP67 - Anodized Aluminium housing + PUR (Polyurethane) cable jacket + LCP (Liquid Crystal Polymer) sensing surface - non-flush mounting - with IO-Link communication capability - equivalent to BAWZ05ACBLD50BBP00.75GS04
compare
USD382.24 Price
Out of Stock - Backorder
