TYA720 HAGER KNX annual digital time switch 4 channels + DCF77 4M

Hager

compare
TYA720 - HAGER

Weekly and yearly digital time switch with 4 channels, equipped with backlit LCD display and programming key. It manages up to 300 programmable steps with ON/OFF, pulse and cycle functions. Powered by the KNX bus with precision of ±0.2 s/24 h and lithium battery with 5-year autonomy. Includes presence simulation, overrides, keypad lock and hour counter for each output. ETS configuration. Compact, occupies 4 DIN modules. Weekly and yearly digital time switch with 4 channels, equipped with backlit LCD display and programming key. It manages up to 300 programmable steps with ON/OFF, pulse and cycle functions. Powered by the KNX bus with precision of ±0.2 s/24 h and lithium battery with 5-year autonomy. Includes presence simulation, overrides, keypad lock and hour counter for each output. ETS configuration. Compact, occupies 4 DIN modules.

MPNs TYA720, HAGTYA720
EAN 3250617579735
HS Code 91070000
Country of origin Germany
Weight 0.23 kg
Download Datasheet
The product image is for illustrative purposes only.
The country of origin, HS code, and description are provided by the manufacturer and may be subject to change without prior notice. For this reason, PLC-City cannot be held responsible for any discrepancies.
Sold by PLC-CITY® and shipped from Italy

We accept many payment methods: Bank Transfer (SEPA, ACH), Debit/Credit Cards (Mastercard, VISA, American Express, Diners Club, Discover, JCB, UnionPay), PayPal, ApplePay, GooglePay, link by Stripe, Cartes Bancaires, Alipay, Bancontact, blik, eps, giropay iDeal, Przelewy24, WeChatPay.
More information about our payment methods

This product is covered by a 12 Months warranty, valid for manufacturing defects or malfunctions. The warranty does not cover damage caused by improper use or accidental damage.
Learn more about our warranty

Returns are subject to prior authorization and eligible for store credit only. Backordered items are excluded.

View our return policy

Available on request

Get your personalized quote now

A dedicated sales representative will assist you to offer the best price and delivery times.

You must be logged

Product information

Technical specifications

Degree of protection (IP)
IP20
Mounting method
DRA (DIN-rail adapter)
Number of channels
4
Width in number of modular spacings
4
Other bus systems
None
With bus connection
TRUE
Bus system KNX
TRUE
External programming
TRUE
Annual program
TRUE
Radio-controlled (DCF77)
TRUE
Summer-/winter switchover
TRUE
Days off programmable
TRUE
Autonomy
43200 h
Presence simulation
TRUE
Sub-clocks controllable over bus-system
TRUE
