BNS 823-D04-R12-100-22-04 BALLUFF - Part Number: BNS018R
NFS
Out of Stock - Backorder
To order from manufacturer
USD573.23

Import Taxes Excluded

You must be logged

BNS 823-D04-R12-100-22-04 BALLUFF - Part Number: BNS018R

BALLUFF

compare
BNS 823-D04-R12-100-22-04 BALLUFF - Part Number: BNS018R
BNS 823-D04-R12-100-22-04 BALLUFF - Part Number: BNS018R

Mechanical multi limit switch with quick-change block + 4 mechanical safety switches + roller plungers - Balluff (100 series) - model BNS 823-D04-R12-100-22-04 - Pre-equipped with a wiring chamber with screw-clamp term. and M25 cable entry - rated for (switch 1-4; AC) 250V - 4 x 1NO+1NC (snap-action contacts; DPST; positive-opening) - Rectangular body with mounting feet - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - with 12mm switch spacing - 2.67Hz max. switching frequency (switch 1-4) - Vertical mounting - EN60204-1 / VDE 0113 / IEC60947-5-1 compliant - DIN 43697 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS823D04R121002204 Mechanical multi limit switch with quick-change block + 4 mechanical safety switches + roller plungers - Balluff (100 series) - model BNS 823-D04-R12-100-22-04 - Pre-equipped with a wiring chamber with screw-clamp term. and M25 cable entry - rated for (switch 1-4; AC) 250V - 4 x 1NO+1NC (snap-action contacts; DPST; positive-opening) - Rectangular body with mounting feet - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - with 12mm switch spacing - 2.67Hz max. switching frequency (switch 1-4) - Vertical mounting - EN60204-1 / VDE 0113 / IEC60947-5-1 compliant - DIN 43697 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS823D04R121002204

MPNs BNS018R, BAUBNS018R, BNS 823-D04-R12-100-22-04
HS Code 8536509055
Country of origin Hungary
Weight N/A
Download Datasheet
The product image is for illustrative purposes only.
The country of origin, HS code, and description are provided by the manufacturer and may be subject to change without prior notice. For this reason, PLC-City cannot be held responsible for any discrepancies.
Sold by PLC-CITY® and shipped from Italy

We accept many payment methods: Bank Transfer (SEPA, ACH), Debit/Credit Cards (Mastercard, VISA, American Express, Diners Club, Discover, JCB, UnionPay), PayPal, ApplePay, GooglePay, link by Stripe, Cartes Bancaires, Alipay, Bancontact, blik, eps, giropay iDeal, Przelewy24, WeChatPay.
More information about our payment methods

This product is covered by a 12 Months warranty, valid for manufacturing defects or malfunctions. The warranty does not cover damage caused by improper use or accidental damage.
Learn more about our warranty

Returns are subject to prior authorization and eligible for store credit only. Backordered items are excluded.

View our return policy

NFS Condition NFS
New Factory Sealed - Original
Out of Stock - Backorder
To order from manufacturer
USD573.23

Import Taxes Excluded

You must be logged
Sold by PLC-CITY® and shipped from Italy
Free express shipping to United States
Loader...
View all shipping services
Request a quote to know the delivery date

We accept many payment methods: Bank Transfer (SEPA, ACH), Debit/Credit Cards (Mastercard, VISA, American Express, Diners Club, Discover, JCB, UnionPay), PayPal, ApplePay, GooglePay, link by Stripe, Cartes Bancaires, Alipay, Bancontact, blik, eps, giropay iDeal, Przelewy24, WeChatPay.
More information about our payment methods

This product is covered by a 12 Months warranty, valid for manufacturing defects or malfunctions. The warranty does not cover damage caused by improper use or accidental damage.
Learn more about our warranty

Returns are subject to prior authorization and eligible for store credit only. Backordered items are excluded.

View our return policy

Get your personalized quote now

A dedicated sales representative will assist you to offer the best price and delivery times.

You must be logged

Request your tailored technical service

Rely on our expert technical team for a range of personalized services: repair, programming, maintenance, and much more.

Product information

Description

Mechanical multiple position limit switches with safety switch positions benefits - Also suitable for welded contacts - Safety functions in accordance with DIN EN 60204-1/VDE 0113 and DIN EN 60947-5-1 - Four model series - Up to 16 switch positions depending on the model series - A freely selectable number of safety switch positions in one multiple position switch - Safety switch positions can be combined with standard switching elements Mechanical multiple position limit switches with safety switch positions benefits - Also suitable for welded contacts - Safety functions in accordance with DIN EN 60204-1/VDE 0113 and DIN EN 60947-5-1 - Four model series - Up to 16 switch positions depending on the model series - A freely selectable number of safety switch positions in one multiple position switch - Safety switch positions can be combined with standard switching elements
