CSEP2K2AA3 - Riello UPS SEP 2200 A3 Sentinel Pro 2200VA

Riello UPS

Online double-conversion UPS rated at 2200 VA (2.2 kVA), active power 1980 W, AVR or double conversion depending on the series, tower format, reinforced metal chassis. Suitable for servers and critical loads. Online double-conversion UPS rated at 2200 VA (2.2 kVA), active power 1980 W, AVR or double conversion depending on the series, tower format, reinforced metal chassis. Suitable for servers and critical loads.

MPNs CSEP2K2AA3, RIECSEP2K2AA3
EAN 8023251006364
HS Code 85044085
Country of origin China
Weight 30 kg

The product image is for illustrative purposes only.
The country of origin, HS code, and description are provided by the manufacturer and may be subject to change without prior notice. For this reason, PLC-City cannot be held responsible for any discrepancies.

Get your personalized quote now

A dedicated sales representative will assist you to offer the best price and delivery times.

10 Available from partners Price and delivery upon quote request
You must be logged

Request your tailored technical service

Rely on our expert technical team for a range of personalized services: repair, programming, maintenance, and much more.

Product information

Description

Sentinel Pro uses Double online technology The expression of maximum reliability and maximum protection for loads such as servers, IT and voice-dated applications. In the dibusiness Continuity applications that require long battery defunction times, it is possible to expand laudonomy reaching several hours with the use of the ER versions equipped with charger. Sentinel Pro uses Double online technology The expression of maximum reliability and maximum protection for loads such as servers, IT and voice-dated applications. In the dibusiness Continuity applications that require long battery defunction times, it is possible to expand laudonomy reaching several hours with the use of the ER versions equipped with charger.

Technical specifications

Width
190 mm
Height
333 mm
Depth
446 mm
Weight
26 kg/km
Voltage type
AC
Bridging time full load
11 min
Suitable for network-management
TRUE
Construction type
Free standing model
USB interface
TRUE
Input voltage
220;240 V
Output voltage
220;240 V
USV- technology
Online
With communication interface RS-232
TRUE
Primary frequency
50;60 Hz
Secondary frequency
50;60 Hz
Number of phases secondary
1
Number of phases primary
1
Auto shut down function
TRUE
Output power factor
0.9
Overall efficiency
98 %
Efficiency in eco-mode
98 %
Input connection
C20
Number of output connections C13
8
Number of output connections fixed connection
8
Output effective power
1980 W
Output apparent power
2200 VA
