Mechanical multi limit switch with 3 mechanical switches + chisel plungers - Balluff (40 series) - model BNS 819-B03-D08-40-10 - Pre-equipped with solder pins + M16 cable entries - rated for (switches 1-3; AC) 250V - 3 x 1NO+1NC (snap-action contacts; SPDT single-pole changeover) - Rectangular body with 4.5mm through-holes - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - with 8mm switch spacing - Vertical mounting - IEC60947-5-1 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS819B03D084010

Mechanical multi limit switch with 2 mechanical switches + chisel plungers + LED function signalling (6-60V) - Balluff (100 series) - model BNS 819-D02-D16-100-10-FD - Pre-equipped with a wiring chamber with screw-clamp term. and M25 cable entry - rated for (switches 1-2; AC) 250V - 2 x 1NO+1NC (snap-action contacts; DPST; self-cleaning) - Rectangular body with mounting feet - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - with 16mm switch spacing - 5Hz max. switching frequency (switch 1-2) - Vertical mounting - IEC60947-5-1 compliant - DIN 43697 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS819D02D1610010FD

Mechanical multi limit switch with 3 mechanical switches + chisel plungers - Balluff (100 series) - model BNS 819-D03-D12-100-10 - Pre-equipped with a wiring chamber with screw-clamp term. and M25 cable entry - rated for (switches 1-3; AC) 250V - 3 x 1NO+1NC (snap-action contacts; DPST; self-cleaning) - Rectangular body with mounting feet - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - with 12mm switch spacing - 5Hz max. switching frequency (switch 1-3) - Vertical mounting - IEC60947-5-1 compliant - DIN 43697 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS819D03D1210010

Inductive limit switch with 1 inductive switch - Balluff (H3 series) - model BES 516-161-H3-L - 7mm sensing range - Pre-equipped with a wiring chamber with screw-clamp term. and 2 x M16 cable entries - 1 x digital output (PNP transistor) (NO (Normally Open) or NC (Normally Closed) operation) - Rectangular body with 6.6mm through-holes - 10-30Vdc (12Vdc / 24Vdc nom.) supply voltage - Rated for -13...+158°F / -25...+70°C ambient - IP67 - Anodized Aluminium housing + PA12 (polyamide) sensing surface - 300Hz max. switching frequency - Flush mounting - IEC60947-5-2 compliant - cam approach direction parallel/longitudinal to mounting surface - function signalling - equivalent to BES516161H3L

Mechanical multi limit switch with 6 mechanical switches + chisel plungers - Balluff (40 series) - model BNS 819-B06-D08-40-10 - Pre-equipped with solder pins + M16 cable entries - rated for (switches 1-6; AC) 250V - 6 x 1NO+1NC (snap-action contacts; SPDT single-pole changeover) - Rectangular body with 4.5mm through-holes - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - with 8mm switch spacing - Vertical mounting - IEC60947-5-1 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS819B06D084010

Mechanical multi limit switch with 6 mechanical switches + chisel plungers - Balluff (40 series) - model BNS 819-B06-D08-40-11 - Pre-equipped with a wiring chamber with screw-clamp term. and 2 x M16 cable entries - rated for (switches 1-6; AC) 250V - 6 x 1NO+1NC (snap-action contacts; SPDT single-pole changeover) - Rectangular body with 4.5mm through-holes - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - with 8mm switch spacing - 3Hz max. switching frequency (switch 1-6) - Vertical mounting - IEC60947-5-1 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS819B06D084011

Mechanical multi limit switch with 6 mechanical switches + chisel plungers - Balluff (40 series) - model BNS 819-B06-D08-40-13 - Pre-equipped with a wiring chamber with screw-clamp term. and 2 x M16 cable entries - rated for (switches 1-6; AC) 250V - 6 x 1NO+1NC (snap-action contacts; SPDT single-pole changeover) - Rectangular body with 4.5mm through-holes - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - with 8mm switch spacing - 3Hz max. switching frequency (switch 1-6) - Vertical mounting - IEC60947-5-1 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS819B06D084013

Mechanical multi limit switch with 6 mechanical switches + chisel plungers - Balluff (46 series) - model BNS 819-B06-D08-46-11 - Pre-equipped with a wiring chamber with screw-clamp term. and M16 cable entry - rated for (switches 1-6; AC) 250V - 6 x 1NO+1NC (snap-action contacts; SPDT single-pole changeover) - Rectangular body with mounting feet - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - with 8mm switch spacing - 3Hz max. switching frequency (switch 1-6) - Vertical mounting - IEC60947-5-1 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS819B06D084611

Mechanical multi limit switch with 6 mechanical switches + chisel plungers - Balluff (46 series) - model BNS 819-B06-D08-46-13 - Pre-equipped with a wiring chamber with screw-clamp term. and M16 cable entry - rated for (switches 1-6; AC) 250V - 6 x 1NO+1NC (snap-action contacts; SPDT single-pole changeover) - Rectangular body with mounting feet - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - with 8mm switch spacing - 3Hz max. switching frequency (switch 1-6) - Vertical mounting - IEC60947-5-1 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS819B06D084613

Mechanical multi limit switch with 6 mechanical switches + chisel plungers - Balluff (61 series) - model BNS 819-B06-D12-61-12-10 - Pre-equipped with a wiring chamber with screw-clamp term. and M20 cable entry - rated for (switches 1-6; AC) 250V - 6 x 1NO+1NC (snap-action contacts; DPST; self-cleaning) - Rectangular body with mounting feet (housing B) - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - with 12mm switch spacing - 5Hz max. switching frequency (switch 1-6) - Vertical mounting - IEC60947-5-1 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS819B06D12611210
