Mechanical limit switch with 1 mechanical safety switch + chisel plunger - Balluff (F 60 series) - model BNS 813-FD-60-183 - Pre-equipped with a wiring chamber with screw-clamp term. and M16 cable entry - rated for (switch 1; AC) 250V - 1 x 1NC (creep-action contacts; SPST; positive-opening) - Rectangular body with 6.6mm through-holes - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - 5Hz max. switching frequency (switch 1) - Horizontal or vertical mounting - EN60204-1 / VDE 0113 / IEC60947-5-1 compliant - DIN 43693 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS813FD60183

Mechanical limit switch with 1 mechanical safety switch + roller plunger + LED function signalling (6-24V) - Balluff (F 60 series) - model BNS 813-FL-60-186-FC - Pre-equipped with a wiring chamber with screw-clamp term. and M16 cable entry - rated for (switch 1; AC) 250V - 1 x 1NO+1NC (snap-action contacts; DPST; positive-opening) - Rectangular body with 6.6mm through-holes - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - 2.67Hz max. switching frequency (switch 1) - Horizontal or vertical mounting - EN60204-1 / VDE 0113 / IEC60947-5-1 compliant - DIN 43693 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS813FL60186FC

Mechanical limit switch with 1 mechanical safety switch + roller plunger - Balluff (F 60 series) - model BNS 813-FR-60-187 - Pre-equipped with a wiring chamber with screw-clamp term. and M16 cable entry - rated for (switch 1; AC) 250V - 1 x 1NO+1NC (snap-action contacts; DPST; positive-opening) - Rectangular body with 6.6mm through-holes - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - 2.67Hz max. switching frequency (switch 1) - Horizontal or vertical mounting - EN60204-1 / VDE 0113 / IEC60947-5-1 compliant - DIN 43693 compliant - cam approach direction perpendicular to mounting surface - equivalent to BNS813FR60187

Mechanical limit switch with 1 mechanical safety switch + roller plunger - Balluff (F 60 series) - model BNS 813-FR-60-186-S80R - Pre-equipped with a male 5-pin M12 connector (right side) + M16 cable entry - rated for (switch 1; AC) 250V - 1 x 1NO+1NC (snap-action contacts; DPST; positive-opening) - Rectangular body with 6.6mm through-holes - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - 2.67Hz max. switching frequency (switch 1) - Horizontal or vertical mounting - EN60204-1 / VDE 0113 / IEC60947-5-1 compliant - DIN 43693 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS813FR60186S80R

Mechanical limit switch with 1 mechanical safety switch + roller plunger + LED function signalling (6-24V) - Balluff (F 60 series) - model BNS 813-FR-60-186-FC - Pre-equipped with a wiring chamber with screw-clamp term. and M16 cable entry - rated for (switch 1; AC) 250V - 1 x 1NO+1NC (snap-action contacts; DPST; positive-opening) - Rectangular body with 6.6mm through-holes - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - 2.67Hz max. switching frequency (switch 1) - Horizontal or vertical mounting - EN60204-1 / VDE 0113 / IEC60947-5-1 compliant - DIN 43693 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS813FR60186FC

Mechanical limit switch with 1 mechanical safety switch + roller plunger - Balluff (F 60 series) - model BNS 813-FR-60-186 - Pre-equipped with a wiring chamber with screw-clamp term. and M16 cable entry - rated for (switch 1; AC) 250V - 1 x 1NO+1NC (snap-action contacts; DPST; positive-opening) - Rectangular body with 6.6mm through-holes - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - 2.67Hz max. switching frequency (switch 1) - Horizontal or vertical mounting - EN60204-1 / VDE 0113 / IEC60947-5-1 compliant - DIN 43693 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS813FR60186

Mechanical single position limit switches with safety switch positions

Mechanical limit switch with 1 mechanical safety switch + roller plunger - Balluff (F 60 series) - model BNS 813-FR-60-183-S80R - Pre-equipped with a male 5-pin M12 connector (right side) + M16 cable entry - rated for (switch 1; AC) 250V - 1 x 1NC (creep-action contacts; SPST; positive-opening) - Rectangular body with 6.6mm through-holes - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - 5Hz max. switching frequency (switch 1) - Horizontal or vertical mounting - EN60204-1 / VDE 0113 / IEC60947-5-1 compliant - DIN 43693 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS813FR60183S80R

Mechanical limit switch with 1 mechanical safety switch + roller plunger + LED function signalling (6-60V) - Balluff (F 60 series) - model BNS 813-FR-60-183-FD-S80R - Pre-equipped with a male 5-pin M12 connector (right side) + M16 cable entry - rated for (switch 1) 6-60V - 1 x 1NC (creep-action contacts; SPST; positive-opening) - Rectangular body with 6.6mm through-holes - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - 5Hz max. switching frequency (switch 1) - Horizontal or vertical mounting - EN60204-1 / VDE 0113 / IEC60947-5-1 compliant - DIN 43693 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS813FR60183FDS80R

Mechanical limit switch with 1 mechanical safety switch + roller plunger - Balluff (F 60 series) - model BNS 813-FR-60-183 - Pre-equipped with a wiring chamber with screw-clamp term. and M16 cable entry - rated for (switch 1; AC) 250V - 1 x 1NC (creep-action contacts; SPST; positive-opening) - Rectangular body with 6.6mm through-holes - Rated for +23...+185°F / -5...+85°C ambient - IP67 - Anodized Aluminium housing - 5Hz max. switching frequency (switch 1) - Horizontal or vertical mounting - EN60204-1 / VDE 0113 / IEC60947-5-1 compliant - DIN 43693 compliant - cam approach direction parallel/longitudinal to mounting surface - equivalent to BNS813FR60183
